Project Description
DM-50 Seven Servo Motors Paper box rolling machine
- Servo-controlled full-automatic production (feeding → forming → curling → collecting), with output of 22-30 pcs/min.
- Works with 200-350g/m² PE coated/greaseproof/silicon paper; customizable aluminum molds for various paper containers (easy to change).
- Accurate servo paper suction; intelligent product sorting & collecting table reduces labor costs.
- 5KW low power consumption, 1.7T robust structure, standard air supply (0.5Mpa, 0.2-0.3 m³/min) for reliable operation.
Description:
|
Machine |
DM-50 Fully automatic intelligent Paper box rolling machine |
|
Cup Size |
400X300(Different Size Mold Exchanged) |
|
Paper Material |
200-350gsm，PE coated paper, greaseproof paper, silicone coated paper, etc. |
|
Speed |
22-30pcs/min |
|
Total power |
5KW |
|
Weight |
1700kg |
|
Overall size |
2200*1100*2100mm |
|
Gas Source Requirement |
Air pressure 0.5 MPa requires an air compressor. |
|
Working Volume |
0.2-0.3 m3/min |
